Low Profile Pushbuttons
Series UB2
LED COLORS & SPECIFICATIONS
Electrical specifications are determined at a basic temperature of 25 ° C. LED circuit is independent of switch operation.
If the source voltage is greater than rated voltage, a ballast resistor is required.
The ballast resistor calculation and more lamp detail are shown in the Supplement; see Supplement Index (page Z1).
Bright, Super Bright, & Bicolor LEDs
Super Bright LED
is Electrostatic
Sensitive
Attention
Electrostatic
Sensitive Devices
Color
5C
Red
Bright LEDs
5D
Amber
5F
Green
Units
Super Bright LEDs
6B 6F 6G
White Green Blue
Bicolor
CF
Red/Green
Units
Forward Peak Current
Continuous Forward Current
Forward Voltage
Reverse Peak Voltage
I FM
I F
V F
V RM
30
20
1.85
5
30
20
2.0
5
25
20
2.1
5
mA
mA
V
V
25
20
3.6
5
25
20
3.5
5
25
20
3.6
5
60/60
48/48
1.8/2.0
5/5
mA
mA
V
V
Current Reduction Rate Above 25 ° C ? I F
0.40
0.42
0.46
mA/ ° C
0.40
0.40
0.40
1.0/1.0
mA/ ° C
Ambient Temperature Range
-25 ° C ~ +50 ° C
-20 ° C ~ +50 ° C
-25 ° C ~ +50 ° C
Super Bright and Bicolor LEDs
Bright
Single Color LED
with 1 element
(+) (-)
Super Bright
Single Color LED
with 1 element
(+) (-)
Bicolor LED
with 6 elements
LC (+)
combine only with cap color
codes 1JB, 2B, and 3JB.
L1 (-)
Red
L2 (-)
Green
Orange color can
be achieved by
lighting red and
green simulta-
neously on the bi-
color LED.
CAP TYPES & COLOR COMBINATIONS
1
AT3074 Sculptured
2
AT3075 Beveled
3
AT3076 Flat
(6.1)
.240
(15.0) Sq
.591
Clear Lens
Translucent
Colored Diffuser
Lens/Diffuser
Colors Available:
Cap
Colors Available:
(5.6)
.220
(15.0) Sq
.591
Translucent
Colored Cap
Lens/Diffuser
Colors Available:
(5.6)
.220
(15.0) Sq
.591
Clear Lens
Translucent
Colored Diffuser
JB
JC
Clear/
White
Clear/
Red
JD
JF
Clear/
Amber
Clear/
Green
B
C
White
Red
D
F
Amber
Green
JB
JC
Clear/
White
Clear/
Red
JD
JF
Clear/
Amber
Clear/
Green
Material: Polycarbonate
Finish: Glossy
Material: Polycarbonate
Finish: Glossy
Material: Polycarbonate
Finish: Glossy
NKK Switches ? email: sales@nkkswitches.com ? Phone (480) 991-0942 ? Fax (480) 998-1435
www.nkkswitches.com
12-02
